D-Link DGS-1005D/E Unmanaged L2 Gigabit Ethernet (10/100/1000) Network Switch Black

D-Link DGS-1005D/E. Switch type: Unmanaged, Switch level: L2. RJ-45 port type: Gigabit Ethernet (10/100/1000), RJ-45 port quantity: 5. Full duplex. MAC address table size: 2000 entries, Switching capacity: 10 Gbit/s. Network standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u. DC input voltage: 5 V

Switch type

Not managed

Switch level

L2

Quality of Service (QoS) support

Yes

Number of RJ-45 ports

5

RJ-45 port type

Gigabit Ethernet (10/100/1000)

Number of SFP modules installed

0

Number of SFP+ modules installed

0

Network standards

IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u

10G support

No

Full duplex

Yes

Auto MDI/MDI-X

Yes

Ethernet LAN Transfer Speed

10,100,1000 Mbit/s

MAC address auto-learning supported

Yes

MAC table dimensions

2000 entries

Switching capacity

10 Gbit/s

Store-and-forward

Yes

Jumbo Frames Support

Yes

Jumbo Frame

9216

Packet transmission rate (1 Gbps)

1488000 pps

Packet transmission speed (100 Mbps)

148,800 pps

Packet transmission speed (10 Mbps)

14880 pps

Packet memory buffer

0.128 MB

Rack mounting

No

Product color

Black

Body material

Plastic

LED indicators

Yes

Mean Time Between Failures (MTBF)

1142330 h

DC input voltage

5 V

Input current

1 A

Power consumption (max)

2.01 W

Power over Ethernet (PoE) support

No

Operating temperature range

0 - 40 °C

Temperature range

-10 - 70 °C

Operating humidity range

10 - 90%

Humidity

5 - 90%

Length

111 mm

Depth

75 mm

Height

30 mm

Weight

80 g

User Manual

Yes

Harmonized System Code (HS)

85176990
