UNIVERSAL BRACKET FOR FIXING WALL-HUNG WC AND BIDET - OTER BASE MODEL

UNIVERSAL BRACKET FOR THE

FIXING SUSPENDED SANITARY WARE

SUITABLE FOR BOTH WC AND BIDET

CHARACTERISTICS:

• Support for fixing the sanitary fixture only, whether it is a WC or BIDET.

• Complies with the standard: UNI EN 997:2004 - Installed in the wall, it is tested for a load of 400 kg.

• Sanitary interaxis: 160 - 180 – 200 - 230 [mm].

• Material: High-strength, hot-dip galvanized Sendzimir structural sheet metal, thickness 20/10.

• The assembly between the uprights and the crosspieces takes place with a PIN/HOLE coupling, blocked by trilobate self-tapping screws, which guarantees rigidity to the structure and the maintenance of the set centre distance.

• Possibility of adjusting the height of the sanitary fixtures during pipe installation.

• The upper crosspiece allows the waste water pipe to be laid from the cistern without any interference, even when it is insulated.

• It is mounted using a PH3 cross-head screwdriver and a 19 mm open-end wrench.

Product Code: 0490Z
