ASUS PRO H510M-C/CSM Intel H510 LGA 1200 (Socket H5) micro ATX

ASUS PRO H510M-C/CSM. Processor manufacturer: Intel, Processor socket: LGA 1200 (Socket H5), Compatible processors: Intel® Celeron®, Intel® Pentium® G. Supported memory types: DDR4-SDRAM, Maximum supported RAM: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III. LAN controller: Intel® I219-LM. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel

Processor manufacturer

Intel

Processor socket

LGA 1200 (Socket H5)

Compatible Processors

Intel® Celeron®, Intel® Pentium® G

Supported memory types

DDR4-SDRAM

Number of memory slots

2

Maximum RAM supported

64 GB

memory slot type

DIMM

Memory channels

Dual channel

ECC compatibility

Non-ECC

Supported memory speeds

2133,2400,2666,2800,2933 MHz

Without buffer

Yes

Supported storage drive interfaces

M.2, SATA III

Discrete graphics support

Yes

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

USB 3.2 Gen 2 (3.1 Gen 2) connectors

0

Number of SATA III connectors

4

Number of SATA II connectors

0

Number of Parallel ATA connectors

0

Audio connector

Yes

Front panel audio connector

Yes

Front panel connector

Yes

CPU fan connector

Yes

Number of chassis fan connectors

2

TPM connector

Yes

Connector with 12V power

Yes

Number of USB 2.0 ports

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports

0

Ethernet LAN ports (RJ-45)

0

Quantity of VGA (D-Sub) ports

1

Quantity of HDMI ports

1

Quantity of DVI-D ports

1

Quantity of eSATA ports

0

PS/2 Ports Quantity

2

Number of IEEE 1394/Firewire ports

0

DisplayPort Quantity

1

DisplayPort version

1.4

Quantity of COM ports

1

Wi-Fi

No

Ethernet LAN connection

Yes

LAN Controller

Intel® I219-LM

Component for

PC

Motherboard Form Factor

micro ATX

Motherboard chipset family

Intel

Motherboard chipset

Intel H510

Audio system

7.1 channels

Audio chip

Realtek ALC897

Supported Windows operating system

Windows 10

PCI Express x1 slot (Gen 3.x)

2

PCI Express x16 slot (Gen 3.x)

1

PCI Express x16 slot (Gen 4.x)

1

PCI slots

1

BIOS Type

UEFI AMI

BIOS Memory Size

128 Mbit

Harmonized System Code (HS)

84733020

Length

244 mm

Depth

216 mm

Height

51 mm

Weight

634 g
